Ive bought a race tech oil pressure gauge. When its turned up its a made in taiwan gauge not the quality one's you associate with the name. It has the sender with it but no wiring diagram or clamp bracket :-S
has anyone else used one of these before and happen to have the wiring instructions?
Any help would be greatly appreciated, I will post pics later as the mrs is on the lappy at the moment.

Edited by wez on 14th Jun, 2011.

one day boost will be mine!

here are the pics of the gauge, wiring and the sensor which has 2 terminals 1 marked S and the other W.L./G

one day boost will be mine!

Mine were the same wiring colours but a slightly different style gauge. .. I guessed, so follow at your own risk..Black gnd, red +12, grn - illumination - the other two I stuck on the sender one way then the other.

cheers, i was thinking along them lines as the red black and green are one side of the cable and the yellow orange wires are the other side.
